四元數的基本運算
Contents
從羅德里格旋轉公式開始
向量 $\vec x’$ 為向量 $\vec x$ 以單位向量 $\vec n$ 為旋轉軸旋轉角度 $\psi$ 所得到的向量
rodrigue's rotation如圖可得
$$
\begin{align}
\vec{v_2} &= \cos \psi \vec{v_1} - \sin \psi \vec{v_3} \\
\vec{v_1} &= \vec{x} - (\vec{n} \cdot \vec{x})\vec{n} \\
\vec{v_3} &= \vec{v_1} \times \vec{n} \\
&= (\vec{x} - (\vec{n} \cdot \vec{x})\vec{n}) \times \vec{n} \\
&= (\vec x \times \vec n) - (\vec n \cdot \vec x) \mathop {\cancel{{\vec n \times \vec n}}}\limits_0 \\
&= \vec x \times \vec n
\end{align}
$$
最後可將 $\vec x’$ 表示為
$$
\begin{align}
\vec x' &= (\vec n \cdot \vec x)\vec n + \vec v_2 \\
&=(\vec n \cdot \vec x)\vec n +\cos \psi (\vec{x} - (\vec{n} \cdot \vec{x})\vec{n}) + \sin \psi (\vec n \times \vec x ) \\
&= (1-\cos\psi)(\vec{n} \cdot \vec{x})\vec{n} + \cos \psi \vec x + \sin \psi (\vec n \times \vec x )
\end{align}
$$
羅德里格旋轉公式
$\vec x’ = (1-\cos\psi)(\vec{n} \cdot \vec{x})\vec{n} + \cos \psi \vec x + \sin \psi ( \vec n \times \vec x)$
四元數以及四元數的基本運算
四元數
四元數是一個由四個參數所組成的集合，包含:
- 實數部 $q_0$
- 虛數部 $q_1i,q_2j, q_3k$ 且 $q_1,q_2, q_3 \in \mathbb{R}$
一個四元數可以表示成:
$$
q = q_0 + q_1i + q_2j + q_3k
$$
其中:
$$
\begin{split}
i^2 &= j^2 = k^2 = ijk = -1 \\
ij &= k, ji = -k \\
jk &= i, kj = -i \\
ki &= j, ik = -j
\end{split}
$$
另外我們可以將四元數分成實數部以及向量化的虛數部進行描述，即:
$$
q = q_0 + q_1i + q_2j + q_3k = q_0 + \vec q = (q_0, \vec q)
$$
四元數單位元素
$$
1 = 1 + 0i + 0j +0k
$$
四元數絕對值
$$
|q| = \sqrt {q_0^2 + q_1^2 + q_2^2 + q_3^2}
$$
單位四元數
若四元數 $q$ 滿足 $|q|=1$ ，則 $q$ 為單位四元數
四元數共軛
$$
q^* = q_0 - q_1i-q_2j-q_3k
$$
四元數反元素
$$
q^{-1} = \frac {q^*}{|q|^2}
$$
四元數加法
$$
\begin{align*}
p + q &= (p_0 + p_1i + p_2j + p_3k) + (q_0 + q_1i +q_2j + q_3k) \\
&= (p_0 + q_0)+(p_1+q_1)i + (p_2+q_2)j + (p_3+q_3)k
\end{align*}
$$
四元數乘法
$$
\begin{align*}
pq =& (p_0 + p_1i + p_2j + p_3k)(q_0 + q_1i + q_2j + q_3k)\\
=&p_0q_0 - (p_1q_1+p_2q_2+p_3q_3) +
p_0(q_1i+q_2j+q_3k) + q_0 (p_1i+p_2j+p_3k) \\&+ (p_2q_3-p_3q_2)i + (p_3q_1 - p_1q_3)j+(p_1q_2-p_2q_1)k\\
=& p_0q_0 - \vec p \cdot \vec q + p_0 \vec q + q_0 \vec p + \vec p \times \vec q
\end{align*}
$$
證明
\begin{align*}
q q^{-1} &= q\frac{q^*}{|q|^2} \\
&= \frac{1}{|q|^2} (q_0, \vec q)(q_0, -\vec q) \\
&= \frac{1}{|q|^2} (q_0^2 + \vec q \cdot \vec q + \mathop {\cancel{q_0\vec q - q_0\vec q + \vec q \times \vec q}}\limits_0) \\
&= \frac {1}{|q|^2} |q|^2 =1
\end{align*}
單位四元數與旋轉變換的關係
我們可以將以單位向量 $\vec n$ 為旋轉軸旋轉角度 $\psi$ 的變換以一個單位四元數描述，即
$$
\begin{align*}
q = \cos \frac{\psi}{2} + \vec n \sin \frac{\psi}{2}\\
q_0 = \cos \frac {\psi}{2}, \vec q = \sin \frac{\psi}{2} \vec n
\end{align*}
$$
其中 $v = (0, \vec v)$ 為一個實數部為 0 的單純四元數，映射關係如圖
mapping vector to quaternion$$
\begin{align*}
L_q(v) &= qvq^{-1} = qvq^* \\
&=(q_0, \vec q)(0, \vec v)(q_0, -\vec q) = (-\vec q \cdot \vec v, q_0\vec v+\vec q \times \vec v)(q_0, - \vec q) \\
&=0+q_0^2 \vec v +(\vec q \cdot \vec v)\vec q + q_0(\vec q \times \vec v) - \vec q \times \vec v \times \vec q - q_0(\vec v \times \vec q) \\
&= q_0^2\vec v + (\vec q \cdot \vec v)\vec q +q_0(\vec q \times \vec v)+(\vec q \cdot \vec v)\vec q -|q|^2\vec v +q_0(\vec q \times \vec v) \\
&= (q_0^2 -|q|^2 )\vec v + 2(\vec q \cdot \vec v)\vec q + 2q_0(\vec q \times \vec v)
\end{align*}
$$
證明
$$
\begin{align*}
L_q(v) &= qvq^{-1} = qvq^* \\
=& (q_0^2 -|q|^2 )\vec v + 2(\vec q \cdot \vec v)\vec q + 2q_0(\vec q \times \vec v) \\
=& (\cos^2 \frac{\psi}{2} - \sin^2 \frac{\psi}{2}) \vec v+2\sin^2 \frac{\psi}{2}(\vec n \cdot \vec v)\vec n \\&+ 2\cos\frac{\psi}{2}\sin\frac{\psi}{2}(\vec n \times \vec v) \\
=&\cos \psi \vec v + (1-\cos \psi)(\vec n \cdot \vec v)\vec n+ \sin \psi(\vec n \times \vec v)
\end{align*}
$$
單位四元數與旋轉矩陣的關係
$$
\begin{align*}
L_q(v) = (q_0^2 -|q|^2 )\vec v + 2(\vec q \cdot \vec v)\vec q + 2q_0(\vec q \times \vec v)
\end{align*}
$$
$$
\begin{align*}
Rv &= (q_0^2 -|q|^2 )I v + 2(q^T v)q + 2q_0(q_\times v) \\
&= [(q_0^2 -|q|^2 )I + 2qq^T + 2 q_0 q_\times]v
\end{align*}
$$
$$
q = \begin{bmatrix}
q_1 \\
q_2 \\
q_3
\end{bmatrix}
, q_\times = \begin{bmatrix}
0 & -q_3 & q_2\\
q_3 & 0 & -q_1 \\
-q_2 & q_1 & 0
\end{bmatrix}
$$
$$
\begin{align*}
R =&(q_0^2 -|q|^2 )I + 2qq^T + 2 q_0 q_\times \\
=& \begin{bmatrix}
q_0^2 - q_1^2 - q_2^2 - q_3^2 & 0 & 0\\
0 & q_0^2 - q_1^2 - q_2^2 - q_3^2 & 0 \\
0 & 0 & q_0^2 - q_1^2 - q_2^2 - q_3^2
\end{bmatrix} \\&+ 2\begin{bmatrix}
q_1^2 & q_1q_2 & q_1q_3\\
q_2q_1 & q_2^2 & q_2q_3 \\
q
_3q_1 & q_3q_2 & q_3^2
\end{bmatrix} + 2q_0\begin{bmatrix}
0 & -q_3 & q_2\\
q_3 & 0 & -q_1 \\
-q_2 & q_1 & 0
\end{bmatrix} \\
=& \begin{bmatrix}
q_0^2 + q_1^2 - q_2^2 - q_3^2 & 2(q_1q_2-q_0q_3) & 2(q_1q_3 + q_0q_2)\\
2(q_1q_2+q_0q_3) & q_0^2 - q_1^2 + q_2^2 - q_3^2 & 2(q_2q_3 - 2q_0q_1) \\
2(q_1q_3-q_0q_2) & 2(q_2q_3+q_0q_1) & q_0^2 - q_1^2 - q_2^2 + q_3^2
\end{bmatrix}\\
=&\begin{bmatrix}
2(q_0^2 + q_1^2) - 1 & 2(q_1q_2-q_0q_3) & 2(q_1q_3 + q_0q_2)\\
2(q_1q_2+q_0q_3) & 2(q_0^2 + q_2^2) - 1 & 2(q_2q_3 - 2q_0q_1) \\
2(q_1q_3-q_0q_2) & 2(q_2q_3+q_0q_1) & 2(q_0^2 + q_3^2) - 1
\end{bmatrix}
\end{align*}
$$
參考資料
範例程式
C++ example:
| |
Output of sample code:
| |
