Recursive Bayes Filter

Edward Wang included in mathematics SLAM

2022-09-03 842 words 4 minutes

Contents

Recursive Bayes Filter

Estimate the state $x$ of a system given observations $z$ and controls $u$ :

Bayes Filter

$$ \begin{align*} bel(x_t) &= p(x_t|z_{1:t}, u_{1:t})= \frac{p(z_t|x_t,z_{1:t-1},u_{1:t})p(x_t|z_{1:t-1},u_{1:t})}{p(z_t|z_{1:t-1},u_{1:t})}&\text {(Bayes' rule)} \\ &=\eta p(z_t|x_t,z_{1:t-1},u_{1:t})p(x_t|z_{1:t-1},u_{1:t}) \\ &=\eta p(z_t|x_t)p(x_t|z_{1:t-1},u_{1:t}) &\text { (Markov assumption)} \\&=\eta p(z_t|x_t) \int p(x_t|x_{t-1},z_{1:t-1},u_{1:t})p(x_{t-1}|z_{1:t-1}, u_{1:t})dx_{t-1} &\text { (Law of total probablility)} \\&=\eta p(z_t|x_t) \int p(x_t|x_{t-1},u_{t})p(x_{t-1}|z_{1:t-1}, u_{1:t})dx_{t-1} &\text { (Markov assumption)} \\&=\eta p(z_t|x_t) \int p(x_t|x_{t-1},u_{t})p(x_{t-1}|z_{1:t-1}, u_{1:t-1})dx_{t-1} &\text { (Independence assumption)} \end{align*} $$

So that Bayes filter can be written as two step process:

Prediction step:

$$ \begin{align} \overline {bel(x_t)} &= \int p(x_t|x_{t-1},u_{t})p(x_{t-1}|z_{1:t-1}, u_{1:t-1})dx_{t-1}\\ &= \int p(x_t|x_{t-1},u_{t})bel(x_{t-1})dx_{t-1} \end{align} $$

Correction step:

$$ \begin{align} bel(x_t) = \eta p(z_t|x_t)\overline {bel(x_t)} \end{align} $$

conclusions

Bayes filter is a framework for state estimation
The dynamics of the robot and its environment are characterized in the form of two probabilistic laws:
1. state transition distribution
2. measurement distribution.

Bayes rule

Starts from conditional probability:

Discrete

$$ \begin{align} p(x|y) &= \frac{p(x,y)}{p(y)} \\ &= \frac{p(y|x)p(x)}{p(y)} \\ &=\frac{p(y|x)p(x)}{\sum_{x'} p(y|x')p(x')} \end{align} $$

Continuous

$$ \begin{align} p(x|y) &= \frac{p(x,y)}{p(y)} \\ &= \frac{p(y|x)p(x)}{p(y)} \\ &=\frac{p(y|x)p(x)}{\int p(y|x')p(x')dx'} \end{align} $$

Law of Total Probability

Discrete case:

$$ \begin{align} P(A) &= \sum_n P(A \cap B_n)\\ &= \sum_n P(A|B_n)P(B_n) \end{align} $$

Discrete case:

$$ \begin{align} P(A) &= \int_{-\infty}^\infty P(A| X=x)dF_X(x)\\ &= \int_{-\infty}^\infty P(A| X=x)f_X(x)dx \end{align} $$

Motion Model and Observation Model

The term $p(x_t|x_{t-1},u_{t})$ is motion model
The term $p(z_t|x_{t})$ is observation or sensor model

Assignment

Consider a robot that navigates in a discrete 1D grid world composed by 15 cells as the one illustrated below.

World Map

The floor can be either black (0) or white (1)

In this world, the robot can move forward (F) or backward (B).

Given a command, it moves according to the following motion model:

with probability 0.7, it moves in the correct direction (i.e. F→F,B→B );
with probability 0.2 or if the command cannot be exectuted (e.g. end of the world!), it does not move;
with probability 0.1, it moves in the opposite direction (i.e.F→B,B→F ).
The initial position of the robot is known and is at cell 7

The sensor is able to recognize that:

a tile is white with probability 0.7
a tile is black with probability 0.9

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
from ex2_1 import *
import numpy as np

belief = np.zeros(15)
x_start = 7
belief[x_start] = 1
belief_init = np.copy(belief)

plot_belief(belief)

observation = [0 , 1, 0, 0, 0, 0, 1, 0, 0, 0]
world = [0, 0, 1, 1, 0, 1, 0, 0, 1, 0, 0, 0, 0, 1, 0]
actions = ['F', 'F', 'F', 'F', 'B', 'B', 'F', 'F', 'B']

for i, action in enumerate(actions):
    belief = motion_model(action, belief)
    plot_belief(belief)

belief = belief_init
belief = recursive_bayes_filter(actions, observation,
                                belief, world)
plot_belief(belief)

localization with odomerty only:

localization with recursive bayes filter:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
#!/usr/bin/env python3
# -*- coding: utf-8 -*-
import numpy as np
import matplotlib.pyplot as plt

def plot_belief(belief):
    plt.figure()
    ax = plt.subplot(2,1,1)
    ax.matshow(belief.reshape(1, belief.shape[0]))
    ax.set_xticks(np.arange(0, belief.shape[0],1))
    ax.xaxis.set_ticks_position("bottom")
    ax.set_yticks([])
    ax.title.set_text("Grid")

    ax = plt.subplot(2, 1, 2)
    ax.bar(np.arange(0, belief.shape[0]), belief)
    ax.set_xticks(np.arange(0, belief.shape[0], 1))
    ax.set_ylim([0, 1.05])
    ax.title.set_text("Histogram")


def motion_model(action, belief):
    p_ff = p_bb = 0.7
    p_fb = p_bf = 0.1
    p_remain = 0.2
    ret = np.zeros(len(belief))

    if action == 'F':
        for i in range(len(belief)):
            if i == 0:
                ret[i] = 0.2 * belief[i] + 0.1 * belief[i+1]
            elif i == (len(belief) - 1):
                ret[i] = 0.2 * belief[i] + 0.7 * belief[i-1]
            else:
                ret[i] = 0.2 * belief[i] + 0.7 * belief[i-1]
                         + 0.1 * belief[i+1]
    else:
        for i in range(len(belief)):
            if i == 0:
                ret[i] = 0.2 * belief[i] + 0.7 * belief[i+1]
            elif i == (len(belief) - 1):
                ret[i] = 0.2 * belief[i] + 0.1 * belief[i-1]
            else:
                ret[i] = 0.2 * belief[i] + 0.7 * belief[i+1]
                         + 0.1 * belief[i-1]
    return ret


def sensor_model(observation, belief, world):
    white_correct = 0.7
    black_correct = 0.9

    ret = np.copy(belief)

    # white observed
    if observation == 1:
        for i, val in enumerate(world):
            if val == 0:
                ret[i] = (1 - white_correct) * belief[i]
            else:
                ret[i] =  white_correct * belief[i]
    # black observed
    else:
        for i, val in enumerate(world):
            if val == 0:
                ret[i] = black_correct * belief[i]
            else:
                ret[i] = (1 - black_correct) * belief[i]

    return ret / np.sum(ret)


def recursive_bayes_filter(actions, observations,
                           belief, world):
    bel = sensor_model(observations[0], belief, world)
    for i, action in enumerate(actions):
        bel_bar = motion_model(action, bel)
        bel = sensor_model(observations[i], bel_bar, world)
    return bel

Video Lecture

Reference

Probabilistic Robotics , Ch2
